GEPRC ELRS DUAL 2 4G Dual Antenna Long Range Low L
... Moreatency Open Source True Diversity Receiver for FPV RC Racer DroneSummaryGEPRC ELRS DUAL 2 4G Diversity Receiver is a new generation of true dual antenna diversity receiver system based on the ExpressLRS open source project ExpressLRS features long range operation low latency maximum 1000Hz refresh rate and low price The ELRS DUAL 2 4G Diversity Receiver has a reasonable placement of dual antennas for wider signal reception and more stable connection than ordinary single antenna receiver systems It uses a TCXO temperature compensated crystal oscillator to avoid frequency shift caused by temperature changes and the telemetry power is up to 100mW Description Brand GEPRCItem ELRS DUAL 2 4G ReceiverChips ESP32 PICO D4 SX1281Crystal Oscillator TCXOFrequency Band 2 4GHz ISMRefresh Rate 25Hz 1000HzInput Voltage 5VAntenna Connector ipex1Indicator Light RGB lightTLM Power 20dBmSize 20 14mmWeight 1 2g RX only Feature 20mm 14mm Small size 1 2g weight WIFI Upgrade firmware ELRS open source project remote control Maximum refresh rate of 1000Hz Two independent RF receiving links true diversity receiver The use of temperature compensated crystal oscillator TXCO no fear of high or low temperature impact more stable performance even if long hours of work is not easy to cause loss of control Built in PA LNA up to 100mW telemetry power BindingThe factory firmware version of ELRS DUAL 2 4G Diversity Rec Less
